Technical Details
Build Specs
| Shimano GRX 600 | |
| Frame | Otso custom butted 4130 Chromoly tubing with Tuning Chip™️ dropout system |
| Fork | Lithic full carbon fork, 12mm thru-axle, triple mounts |
| Headset | FSA Orbit ITA Headset, black |
| Drivetrain | Shimano GRX 600 1x12 mechanical |
| Rear derailleur | Shimano GRX 822, 12-speed, RD-RX822 |
| Front derailleur | n/a |
| Shifters | Shimano GRX 610, BL-RX610 |
| Cassette | Shimano SLX, 10-51T, 12-speed, CS-M7100 |
| Brakes | Shimano GRX 410 Hydraulic, BR-RX410 |
| Cranks | Shimano GRX 610 with 40T chainring, FC-RX610-1, length scaled with frame size: 165mm for 49cm frames, 170mm for 52cm and 54cm frames, 172.5mm for 56cm and 58cm frames, 175mm 60cm frames |
| Bottom bracket | Shimano English threaded BSA, 68mm, SM-BBR60 |
| Handlebar | Lithic Aventurine; 16 deg flare, 5 deg sweep, 120mm drop, 70mm reach; scaled with frame size: 40cm bars for 49cm frames, 42cm bars for 52cm frames, 44cm bars for 54cm and 56cm frames, 46cm bars for 58cm and 60cm frames |
| Handlebar tape | Anti-Slip Gel Bar Tape |
| Stem | Aluminum; black; length scaled with frame size: 50mm for 49cm, 60mm for 52cm, 70mm for 54cm, 80mm for 56cm, 90mm for 58cm, 100mm for 60cm |
| Seatpost | 27.2x350mm; 6061 aluminum; black |
| Seatpost Clamp | 29.8mm; CNC aluminum; black |
| Saddle | WTB Silverado Medium; Steel; 142x265mm |
| Wheels | Hayes Duroc 30 Comp: 650b for 49cm frame; 700c for 52cm-60cm frames |
| Tires | Schwalbe G-One Allround Perf, RaceGuard, TLR, 650x40 for 49cm frame; Schwalbe G-One RS Performance, RaceGuard, TLR; 45mm for 52-60cm frames; tan sidewall |
| Chain | Shimano SLX 12-speed, CN-M7100 |
Frame Specs
| Sizes 52cm-60cm | |
| Bottom bracket standard | 68mm BSA threaded |
| Q factor | 146mm with Shimano RS510 crankset |
| Maximum chainring size | 2x: 53T round / 31T round; 1x: 50T round or 46T oval |
| Minimum Chainline | 47.5mm |
| Front derailleur type | 28.6mm clamp, bottom pull |
| Headset | ZS44/28.6 upper, EC44/40.0 lower |
| Seatpost diameter | Ø27.2mm |
| Internal dropper post routing | Yes, exit port on bottom of seat tube |
| Seatpost clamp | Ø29.8mm |
| Front/rear hub standard | 100x12mm thru axle / 142x12mm thru axle |
| Front/rear axle | Ø12x125mm front, TP=1.5, TL=12mm / Ø12x180mm rear, TP=1.5, TL=12mm |
| Derailleur hanger | Wolf Tooth Tuning Chip Right Dropout |
| Rear brake (rotor) | Flat mount, 74mm post mount available(160mm) |
| Front brake (rotor) | Flat mount native, 74mm post mount adapter available (160mm) |
| Fork axle-to-crown | 420mm, suspension corrected up to 40mm travel |
| Fork offset | 47mm |
| Bare frame weight | 5.53 lbs / 2509 g (size 56cm) |
| Fork weight (Lithic Hiili) | 490 g |
| Tire clearance (frame) | 700c & 650b x 40mm at 420mm chainstay position; 700c & 650b x 50mm at 430/440mm chainstay positions |
| Tire clearance (fork) | Max clearance 29" x 2.1" (54-622) |
| Braze-ons | Three bottle frame mounts, fender, rack, cable clamps, two three-pack mounts on fork |
| Seatpost Insertion Depth | 52cm: 310mm; 54cm: 290mm; 56cm: 290mm; 58cm: 310mm; 60cm: 330mm |
| Max weight (rider + gear) | 275 lbs. |
| Max spacer stack under stem | 40mm |
| Max spacer stack above stem | 10mm |
| Max stem bolt torque | 6 Nm |
| Frame Bag Dimensions | 52cm 54cm 56cm 58cm 60cm |
Geometry
| 49cm | 52cm | 54cm | 56cm | 58cm | 60m | |
| Recommended rider height | 4'11"-5'2" | 5'2"-5'4" | 5'4"-5'8" | 5'8"-6'0" | 6'0"-6'2" | 6'2"-6'5" |
| Recommended rider inseam | 25"-29" | 28"-30" | 30"-33" | 32"-34" | 33"-35" | 34"-37" |
| Effective top tube | 510mm | 530mm | 545mm | 565mm | 580mm | 600mm |
| Nominal head tube angle | 70° | 70.5° | 71° | 71.5° | 72° | 72° |
| Tuning Chip-induced head/seat tube angle change from middle position | ±0.25° | ±0.25° | ±0.25° | ±0.25° | ±0.25° | ±0.25° |
| Head tube length | 87mm | 95mm | 115mm | 140mm | 165mm | 185mm |
| Nominal seat tube angle | 75° | 74.5° | 74° | 73° | 72.5° | 72° |
| Seat tube length | 400mm | 505mm | 530mm | 550mm | 570mm | 590mm |
| Bottom bracket drop | 58-62mm | 68-72mm | 68-72mm | 68-72mm | 68-72mm | 68-72mm |
| Chainstay length | 410-430mm | 420-440mm | 420-440mm | 420-440mm | 420-440mm | 420-440mm |
| Wheelbase | 1000-1020mm | 1017-1037mm | 1023-1043mm | 1028-1048mm | 1032-1052mm | 1046-1066mm |
| Trail | 70mm | 71mm | 70mm | 67.5mm | 65mm | 65mm |
| Fork offset | 47mm | 47mm | 47mm | 47mm | 47mm | 47mm |
| Rigid fork axle to crown length | 420mm | 420mm | 420mm | 420mm | 420mm | 420mm |
| Stack | 532mm | 549mm | 570mm | 596mm | 622mm | 641mm |
| Reach | 368mm | 378mm | 381mm | 383mm | 384mm | 392mm |
| Standover | 677mm | 760mm | 780mm | 800mm | 820mm | 840 mm |
