Frameset
- Frame
- Specialized Diverge E5 Premium Aluminum, SWAT™ Door integration, Future Shock suspension, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc, UDH dropout
Suspension
- Fork
- Future Shock 3.1 w/ Smooth Boot, FACT Carbon 12x100mm, thru-axle, flat-mount disc
Brakes
- Front Brake
- Shimano CUES Hydraulic Brake
- Rear Brake
- Shimano CUES Hydraulic Brake
Drivetrain
- Chain
- Shimano CN-LG500
- Bottom Bracket
- Shimano Threaded BSA BB
- Shift Levers
- Shimano CUES ST-U6030
- Rear Derailleur
- Shimano CUES 11-speed w/ Shadow Plus
- Cassette
- Shimano, CS-LG400-11, CUES, 11-Speed, 11-50t
- Crankset
- Shimano CUES FC-U6040, 40t
Wheels & tires
- Front Wheel
- AXIS Elite Disc
- Rear Wheel
- AXIS Elite Disc
- Front Tire
- Tracer 700x45, Tubeless Ready
- Rear Tire
- Tracer 700x45, Tubeless Ready
- Inner Tubes
- Presta, 700x32-50mm
Cockpit
- SeatPost
- Alloy, 2-bolt Clamp, 12mm offset, 27.2mm, anti-corrosion hardware
- Seat Binder
- Alloy, 30.8mm
- Saddle
- Body Geometry Power Sport, steel rails
- Stem
- Future Stem, Comp
- Handlebars
- Specialized Adventure Gear Hover, 103mm drop x 70mm reach x 12º flare
- Tape
- Supacaz Suave
Accessories
- SWAT
- SWAT 3.0 internal downtube storage
Product details
- Product ID
- 223511
Weight
- Weight
- 10.74 kg (23 lb, 10.8 oz)
- Weight Size
- 56
Geometry
| 49 | 52 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|
| Crank Length | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
| Handlebar Width | 380 | 400 | 420 | 420 | 440 | 440 |
| Stem Length | 60 | 70 | 80 | 90 | 100 | 100 |
| Saddle Width | 155 | 155 | 143 | 143 | 143 | 143 |
| Seatpost Length | 350 | 350 | 400 | 400 | 400 | 400 |
| Stack | 563 | 578 | 592 | 610 | 634 | 659 |
| Reach | 365 | 374 | 387 | 400 | 412 | 425 |
| Head Tube Length | 90 | 104 | 116 | 135 | 161 | 187 |
| Head Tube Angle | 70 | 70.5 | 71 | 71 | 71 | 71 |
| BB Drop | 85 | 85 | 85 | 85 | 85 | 85 |
| Trail | 72 | 68 | 65 | 65 | 65 | 65 |
| Fork Length, Full | 391 | 391 | 391 | 391 | 391 | 391 |
| Fork Rake/Offset | 55 | 55 | 55 | 55 | 55 | 55 |
| Front Center | 604 | 613 | 626 | 645 | 665 | 686 |
| Chainstay Length | 430 | 430 | 430 | 430 | 430 | 430 |
| Wheelbase | 1019 | 1031 | 1041 | 1060 | 1081 | 1102 |
| Top Tube Length, Horizontal | 521 | 537 | 556 | 575 | 593 | 613 |
| Bike Standover Height | 700 | 725 | 754 | 779 | 805 | 832 |
| Seat Tube Length | 400 | 430 | 470 | 500 | 530 | 560 |
| Seat Tube Angle | 74.5 | 74 | 74 | 74 | 74 | 74 |
